Jello Cube Simulation

Simulating a Mass-Spring System
Pranav Rathod

Date: February 19, 2025

For this assignment, I successfully implemented a physically based simulation of a Jello Cube using a mass-spring system. The cube deforms, oscillates, and reacts realistically to forces based on Newton’s laws of motion, Hooke’s law, and damping forces.

Video Demonstration

Core Features Implemented:

  • Acceleration Computation (computeAcceleration() in physics.cpp):

    • Structural, shear, and bend spring forces
    • External force field (if present)
    • Collision response with the bounding box

    The elasticity of the Jello Cube is modeled using a mass-spring system, where forces follow Hooke’s Law:

    F=k(xx0)F = -k \cdot (x - x_0)
    • F: restoring force
    • k: spring constant
    • x: current length
    • x0: rest length

    Each mass point connects to others via structural, shear, and bend springs, allowing the cube to deform and recover naturally.

    • Damping Forces: To stabilize the system and reduce oscillations, damping forces are computed as:

      Fd=kd(vAvB)LLF_d = -k_d \cdot \frac{(v_A - v_B) \cdot L}{|L|}
      • k_d: damping coefficient
      • (v_A - v_B): velocity difference
      • L: displacement vector between connected points
  • Euler and RK4 Integration: Both integration methods were implemented to advance the simulation over time with tunable timestep values.

    • Collision Detection & Penalty Response (Bounding Box): Ensures all control points stay within [-2, 2] by applying a spring force when out of bounds.

      Fc=kc(pboundaryp)F_c = k_c \cdot (p_{boundary} - p)
  • External Force Field: Trilinear interpolation was used to calculate external force values from a 3D grid defined in the .w file.

    1. Grid Indexing – mapping position to force grid
    2. Interpolation – blending 8 surrounding vectors
  • OpenGL Visualization:

    • Wireframe and shaded surface rendering modes
    • Real-time camera controls
    • Toggle visibility for structural, shear, and bend springs

Extra Credit Implemented

Inclined Plane Collision

  • Supported via user-defined coefficients in the world file:

    ax+by+cz+d=0a \cdot x + b \cdot y + c \cdot z + d = 0
  • Rendering: Drawn dynamically in showInclinedPlane() using 4 corners based on the plane equation.

  • Collision Detection & Response:

    • Each control point is checked against the plane.
    • If below, a penalty force pushes it above the surface.
    • Includes damping opposite to velocity to absorb energy.
  • Implemented in applyCollisionForces() inside physics.cpp.

The inclined plane adds more complexity and realism to the cube’s motion and response.


Development Environment

  • OS: MacOS
  • Editor: Visual Studio Code
  • Compiler: Clang++ (C++17)
  • Build System: Makefile
  • Libraries: OpenGL, GLUT (Mac Frameworks)

Compilation Instructions

  1. Build the project

    make
  2. Run the simulation with a world file

    ./jello world/jello.w
  3. Create a world file

    ./createWorld
  4. Clean build artifacts

    make clean

Note: The Makefile auto-detects MacOS and links the correct OpenGL/GLUT frameworks.


Notes

  • The simulation was tested using multiple world files including custom-generated ones.
  • Performance is interactive with frame rates > 15fps at 640x480.
  • A Mac executable is included, but the grader may recompile on Windows as needed.
